7.5 Assistance with troubleshooting
Error
Control unit does
not respond or does
not respond to
several functions
Body functions
cannot be
switched on at the
touch panel in the
driver's cab.
Plateau does not or
not completely tilt
up
Operating Instructions Algema Blitzlader 2 Air - Edition
Cause
Fuse defective
Parking brake
not applied
Car transporter
ignition off
Discharge
vehicle battery
Set-up functions
are not switched
on
Function for manual
control or radio
remote control not
correctly selected
The end position
sensor switches off
the electro-
hydraulics.
The tilt sensors
switch off the electro-
hydraulics even
though the rear of the
platform does not
touch the ground.
Oil level of the
electro-hydraulics too
low
Remedy
Check fuses
Activate parking
brake
Switch on ignition
Start the engine, if
necessary start it
externally
Switching on the
set-up functions on
the touch panel
Activate the function
of the hand control
or radio remote
control as desired.
Check the settings,
the control LEDs
must not light up as
long as the tilt
scissors have not
reached the end
position.
Check free
movement and
adjustment, control
LEDs on the sensor
must not light up as
long as the plateau
on the board is not
yet in place.
Check oil level and
top up if necessary
7 Additional
Chapter
see "Fuses", page 76
see "Tilt plateau
operation ", page
21
see "Tilt plateau
operation ", page
21
Operating instructions
base vehicle
see "Tilt plateau
operation ", page
21
see "Tilt plateau
operation ", page
21
see pictures below
Sensors
see "Lubricating and
greasing moving
parts", page 72
see pictures below
Sensors
see "Checking the
oillevel and oil
change", page 70
