The loaded vehicle is positioned incorrectly!
The rope is damaged!
Also observe the separate operating instructions for the cable winch and
the safety instructions under
unloading".
den", page 16.
The installation situation of the cable winch may differ from the original
installation instructions of the cable winch. For a straight pull and for rope
shearing, use the following
The rope is always wound up from above, observing the prescribed
direction of rotation of the rope winch.
Winch operation:
Operating Instructions Algema Blitzlader 2 Air - Edition
Axle loads of the car transporter are exceeded.
The car transporter is no longer steerable due to a relieved front
axle.
° The loaded vehicle must be positioned in such a way that the
permissible axle loads of the car transporter are not exceeded.
° To ensure steerability, the front axle load of the car transporter
must be more than approx. 30% of the actual weight of the
loaded car transporter.
Injuries caused by the rope.
The rope can break.
°Wear work gloves.
°Damaged ropes must not be used
67).
(see "Checking ropes", page
"Safety instructions for loading and
Winch:
1. Free running
2. Side sliding protection
3. Handle
4. Storage hook
5. Cable remote control connector
4 Operation and use
