Loaded:
•
Secure the loading point
•
Extend the drive-up ramps and tip up the plateau
plateau", page 21).
•
Check the position of the front wheel stop and change it if necessary
"Securing the loaded vehicle", page 23).
•
Release the rope hook from the storage eye (4) and pull the rope from the drum
with the freewheel (1) activated.
•
Attach the cable hook to the vehicle to be loaded and disengage the freewheel (1).
Pull the cable firmly again to ensure that the freewheel clutch is correctly engaged.
The overrunning clutch does not engage correctly when the
overrunning clutch of the cable winch is deactivated!
At least 5 rope windings must remain on the drum to be able to hold the
nominal load.
To attach the rope hook to the vehicle to be towed, follow the operating
instructions for the vehicle.
•
The vehicle can now be slowly pulled onto the plateau with the cable winch in the
middle of the car transporter's centre longitudinal axis until the front wheels are at the
wheel stop. Observe the position of the steered wheels and correct if necessary.
Make sure that the rope is wound neatly onto the drum.
Non-adapted steering movements when loading!
•
On the loaded vehicle, apply the parking brake and engage the lowest gear or, in the
case of automatic transmission, move the selector lever to the P position.
•
Tilt the plateau and retract
Operating Instructions Algema Blitzlader 2 Air - Edition
(see "Loading and unloading point", page 20).
The drum can rotate uncontrollably when a load is applied and the
coupling will be damaged.
°After deactivating the freewheel, pull the rope again
firmly so that the freewheel clutch engages securely.
Do not operate the freewheel under load.
The vehicle to be loaded can fall from the ramps or from the plateau.
°Full the vehicle straight onto the car transporter, call in a
guide if necessary.
the ramps
(see"Operation of the tipping
(see "Tilt plateau operation", page 21).
4 Operation and use
(see
