If the plateau is not fully tipped, a warning tone sounds in the driver's
cab for approx. 20 seconds when the parking brake is released. There
is no warning tone for ramps that are not fully retracted.
When the parking brake is released, the overrun functions are deactivated
immediately. If the ignition goes out, the opener functions deactivate after
the parking brake is released.
approx. 60 sec. Follow-up time.
There is no automatic switch-off for the hydraulic functions except for
tipping up. As soon as the movement stops, the button must be
released.
be left in place. If the electrohydraulics work against a large resistance for
a long time, there is a risk of damage due to overheating.
The battery voltage is not monitored during operation of the
electrohydraulics. Due to the high current demand, it can happen that the
battery is not
the engine and frequent operation of the electrohydraulic system may
cause the vehicle batteries to discharge. It is recommended to keep the
engine running during the charging and discharging process.

4.1.4 Securing the loaded vehicle

•
Determine the position of the front wheel stop, depending on the wheelbase, the
overhangs and the axle load distribution of the vehicle to be transported.
•
With the turnbuckle open, hook the wheel stop into the holes in the railing with the
pins on the opposite side to the turnbuckle. The turnbuckle must point forwards.
•
Align the wheel stop exactly transverse to the direction of travel and close the
turnbuckle so that the pins of the wheel stop are fixed in the holes of the railing.
Operating Instructions Algema Blitzlader 2 Air - Edition
4 Operation and use
23/ 100
