The actuating mechanism is damaged!
4.8

Lift axle*

The car transporter is optionally equipped with a manual lift axle function for the third axle.
This allows the third axle to be lifted when driving empty, reducing tyre wear and fuel
consumption. Furthermore, the traction of the drive axle is improved during empty runs and
slippery road conditions, as a higher proportion of the weight rests on the second axle. The
cable handle for lifting the third axle is located directly next to the hand control panel on the
outside left.
1. Hand control panel
2. Rope pull handle
3. Catch hook
4. Air-termination rod
Lifting the third axle with a loaded car transporter!
Operating Instructions Algema Blitzlader 2 Air - Edition
The centre ramp can slide backwards during travel and fall out of
the ramp shaft.
Before driving off, check that the operating mechanism holds the
ramps securely by pulling once firmly on the centre ramp.
If the operating mechanism is defective, it must be repaired or the
centre ramp must be additionally secured or dismantled.
The axle construction can be overloaded and damaged.
The lifting of the third axle is only permitted with an unladen
vehicle.
4 Operation and use
49/ 100
