ERNI cable routing in the Flat Flange
The ERNI cable, which allows the connection of 2 qbmoves, can be placed inside the flat flange
in two ways; First one is shown in Figure 4-11.
Figure 4-11: First possible ERNI cable routing inside a flat flange
Another way is shown in Figure 4-12.
Figure 4-12: Second possible ERNI cable routing inside a flat flange
