Expansion Interface II Connector (J1)
is a board-to-board connector providing signals from the external bus
J1
interface unit (EBIU) of the processor. The connector is located on the
left edge of the board. For more information, see
on page
1-26. For availability and pricing of the connector, contact
Samtec.
Part Description
104-position 0.025", SMT header
104-position 0.025", SMT socket
RS-232 Connector (J2)
Part Description
DB9, female, vertical mount
2m female-to-female cable
Power Connector (J3)
The power connector (
the EZ-Board.
Part Description
0.65 mm power jack
5.0VDC@2.5A power supply
ADSP-BF518F EZ-Board Evaluation System Manual
ADSP-BF518F EZ-Board Hardware Reference
Manufacturer
SAMTEC
Mating Connector
SAMTEC
Manufacturer
NORCOMP
Mating Cable
DIGI-KEY
) provides all of the power necessary to operate
J3
Manufacturer
CUI
Mating Power Supply (shipped with the EZ-Board)
CUI STACK
"Expansion Interface II"
Part Number
QMS-052-11-L-D-A
QFS-052-01-L-D-A
Part Number
191-009-213-L-571
AE1020-ND
Part Number
045-0883R
DMS050260-P12P-SZ
2-21
