Inputs
Maximum voltage (DC)
Maximum current (DC)
Notes
Outputs
Maximum switchable
voltage (AC/DC)
Maximum switchable
current (AC/DC)
Maximum power
Notes
Figure 6.2-3 - 25-pin output connector
DD1010 FLYNET
+24 V
40 mA
Inputs can be controlled by dry contact outputs (e.g. relays) or NPN NO
transistor outputs
24V
190 mA
800 mW
Dry contact output (solid state contact - optomos)
90
