Bilanciai DD1010 Quick Start

DD1010
1. Unpacking and Installing
Take the terminal and documents out of the packaging.
Version with connectors
2 3
4
8
1
5
7
6 9
Version with cable glands
1
Install the terminal
2.
Available
connections:
1. Slot for optional
cards
International Settings
2. Scale 1
3. Scale 2
4. COM2 Port
- International settings:
5. COM1 Port - User interface language:
- Input language:
6. Expansion for
SD card
7. Ethernet Port
10/100 Mbps
8. USB HOST Ports
3.
9. Power supply
12V
(via external po-
wer supply unit)
Available
connections:
1. USB HOST Ports
•
Slot for optional
cards
•
Scale 1
TOUCH-SCREEN calibration
•
Scale 2
•
COM2 Port
•
COM1 Port
•
Expansion for
4.
SD card
•
Ethernet Port
10/100 Mbps
•
Power supply
110/240 Vac
Network settings
Press to access
the terminal.
Once the configurations have been carried out, wait until the appli-
cation is fully loaded and the archives are activated.
Language setting
Press the touch-screen within
5 seconds of switching it on.
Select"International Settings".
English
English
EN
Press "OK".
OK
Touch-screen calibration
Press the touch-screen within
5 seconds of switching it on.
Select "TOUCH-SCREEN
Calibration" to recalibrate the
screen (follow the guided pro-
cedure).
Network setting
Press the touch-screen within
5 seconds of switching it on.
Select "Network settings" to
set the network parameters re-
lative to the connection (follow
the guided procedure).
