Bilanciai DD1010 FLYNET Use, Maintenance And Installation Manual page 45

To create a network scale click on the "ADD" button on the scale display page.
It is possible to have up to 2 internal scales and 4 total scales (e.g. 2 in the network and 2 internal or
4 in the network)
Then select Network Scale and set the following parameters:
IP address
Port
Remote Scale name
Protocol
Save and return to the weighing page to check that the network scale has been created.
Attention: the specific settings of each weighing instrument must be made through the instrument to
which the scale is connected, they cannot be performed using network infrastructure.
DD1010 FLYNET
Enter here the IP address of the main indicator, i.e. whose weight you
want to repeat.
The default port is 5001, do not change it.
It is possible to choose which scale to repeat simply by writing its name
in this box.
The communication protocol between indicators is XML, it cannot be
changed.
43
