5.13

Adding an external printer

To connect a printer to the indicator, simply follow this procedure:
1. Navigate to the 'Printers / Readers / IOs'
Configuration / System;
2. Select the Printers tag;
3. Select the Printers item so that its background turns white
4. Select the 'Add'
and confirm to proceed;
5. Now the new instance created is displayed, select model and connection COM, save and exit;
6. Select
7. Once inside the COM configuration menu, set the parameters according to the printer
communication specifications, the Flynet indicator does not foresee the use of hardware
Handshake, at the end save and exit the COM menu
8. Exit the System menu by pressing Close, you are now in the configuration menu, press
'Application' and then 'Others'
9. select
10. In this page set the created printer as the primary (or secondary if you have another printer) and
then save and exit;
11. Before using the printer perform a test, select Info from the Tools menu and then Test;
12. Select Print;
13. A page opens that shows the possibility to set the test you want to perform
Printers
Filter
Layout
At the end of the print tests, it is possible to exit and return to normal operation.
If the test does not work, check the connection cable between the indicator and the printer, usually a
label is present to avoid reversing the connectors; also check the printer settings if necessary, to
access the configuration menu refer to the specific printer manual.
If the problem persists, check the printer configuration starting from step 5 to step 13.
DD1010 FLYNET
icon, a form will open to rename the printer, then write the desired name
'Serial Ports' and once in the menu move to the same COM used for the printer
'Printer';
Select the printer to be tested
Select the layout format type, to make a simple test select the *.bpl
format
Select adrinput.bpl to perform a complete test and press the Print key
menu, to reach it follow the path Menu / Tools /
