3.3

Connecting the indicator to the weighing platform

For the connection of the indicator to the weighing platform, a pre-wired cable is normally supplied
whose female connector must be fully inserted into the 9/15 pin male connector (JBIL) located at the
bottom of the indicator. The connection can be different depending on the type of transducer that is
fitted on the weighing platform: analogue or digital.
WARNING
The cable shield must always be connected to the metal protection cap of the 9/15 pin connector.
Do not insert the connection cable to the weighing platform into routes with cables directed to
power drives.
