3.3.3

Digital Scale serial connection

15-pin female D-sub connector.
PIN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
NC = Reserved do not connect
The connection to the digital cells is made with serial transmission type RS485 using a shielded 6-
conductor cable.
The pins with the same signal can be connected in parallel.
3.3.4

Analogue Scale serial connection

9-pin male D-sub connector.
PIN
1
2
3
4
5
6
7
8
9
NC = Reserved do not connect
DD1010 FLYNET
DESCRIPTION
485-
EX +
EX +
EX -
EX -
485+
NC
NC
EX -
NC
NC
NC
NC
NC
NC
DESCRIPTION
SIG-
SIG+
EXC+
EXC-
SENSE+
NC
NC
SENSE-
NC
