1 PT sampling the full scale value.
Removing the weights in inverse order samples the descent.
The sampling procedure is the same as that used by the full scale zero system,
but in this case several points must be sampled.
Hysteresis At least 3 sample weights are required for the hysteresis correction at two points,
Linearis. one for sampling the 1st intermediate point, the second to add to the 1st for
2 PT sampling the 2nd intermediate point, the third to add to the first two for sampling
the full scale value.
Removing the weights in inverse order samples the descent.
The sampling procedure is the same as that used by the full scale zero system,
but in this case several points must be sampled.
Inverse Inverse sampling can be useful in some cases when it is difficult to load and
Sampling unload the known weight from the weighing device, for example in hoppers or
batching systems.
Correction It allows correcting the scale sampling, without re-sampling, knowing the error
made at the maximum capacity; set the value you want to add with sign (e.g.: the
weight excess is 200 kg, set -200).
Estimated It allows calibrating the scale by entering characteristic data of the scale/cells.
sampling ATTENTION this is not a real calibration and the scale may not weigh correctly.
Number of cells
Capacity (kg)
Max. cell capacity (kg)
Initial tare (kg)
Decentralise Better known as angle turn, it allows addressing and calculating the slope for
d load every single cell through wizard. There are 2 methods to perform the angle turn:
Sort by side
Sort by cell
number
Procedure
DD1010 FLYNET
Number of cells
Maximum Scale Capacity
Nominal single cell capacity
Structure Tare
The angle turn is performed first on the odd cell side
and then on the even cell side
The angle turn is performed in numerical order from
cell number 1 to the final cell
Unload the scale, only when the scale is unloaded
press Sample;
Select one of the 2 methods between sort by
address or by side and sample to continue.
Now check on the screen on which cell the weight is
to be placed, place the weight on it (the minimum
weight must be calculated in this way
) and press Sample, wait a few
seconds and proceed in the same way in the order
shown by the indicator.
At the end of the procedure the indicator prompts to
continue by pressing the Calculate Coefficients
button. Once the coefficients are shown on the
display, it is possible to confirm and save or delete
the procedure. If the coefficients are within the
default ranges, the indicator shows a message
indicating the correct angle calibration, otherwise
