DELIVERY AND INSTALLATION
3
2
10
6
1
8
4
7
11
9
5
Figure 3-1 - Indicator bottom with connectors
Key:
1. Slots for optional boards
2. Scale 1
3. Scale 2
4. HDMI port (optional)
5. I/O port
6. COM4 port
7. COM6/ 7 port
8. Ethernet port 10/100 Mb/s
9. USB HOST ports
10. Serial board expansion (optional)
11. 12 V power supply (through external power supply unit)
