Signode Little David LD16AE 2.0 Operator's Manual page 98

4
D
2
C
5
B
A
4
3
11
3
4
6
(PNEUMATIC CARTRIDGE ONLY)
3
12
1
PART #
MAT'L
STD
ST. ST.
STAINLESS : NO FINISH
THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF
LOVESHAW-ITW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY
INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE
REPRODUCED OTHER THAN FOR YOUR OWN USE OR TO BE DISCLOSED TO OTHER
WITHOUT THE EXPRESSED WRITTEN CONSENT OF LOVESHAW-ITW AND WILL BE
RETURNED TO LOVESHAW-ITW UPON REQUEST.
2
13
PARTS FOR CAC61NTNC 3" CARTRIDGE
ITEM QTY PART NUMBER
1 1 SPH-1501
2 1 CAC60-0116A-3
3 1 FHJNSDP
4 1 N401-359
5 1 N400-207
6 1 N400-161
7 1 SP16-0358-4
11 2 FHFNMEP
12 2 FLWMEP
13 2 FFHME012P10
7
KNIFE ARM CYL. ASSY.idw
CAD FILE
TOLERANCES UNLESS
OTHERWISE NOTED:
6/5/2012
PLOT DATE
+ -
.X = .050
- TITLE
6/5/2012
DRAWN DATE
+ 
+
INCH .XX = .015 - -
ANGLES 1/2
-
+
.XXX = .005
DO NOT SCALE PRINT -
+
.X = 1.0mm -
MACH.
+ DWG NO
= .3mm 125
METRIC .XX -
FINISH
+
.XXX = .1mm
-
MATERIAL
+ -
FRACTIONS 1/64
DRAWN
2
1
REVISION HISTORY
REV DESCRIPTION DATE BY
A RELEASED 6/5/2012 BJF
D
Parts List
DESCRIPTION SS MI
CLEVIS PIN SS
CLEVIS
#10-32 HEX JAM NUT P-S
COMPACT CYLINDER SS
MUFFLER
FITTING M5
CYLINDER MOUNT SS
M4 HEX NUT P-S
LOCK WASHER M4 P-S
C
M4x12 LG P-S
B
LOVESHAW
A
an ITW Company
RT. 296, SOUTH CANAAN, PA.
KNIFE ARM CYL. ASSY.
KNIFE ARM CYL. ASSY.
SCALE
CHECKED
BRYCEF
APPROVED
