Signode Little David LD16AE 2.0 Operator's Manual page 93

4
PARTS FOR .CAC61NTNC 3" CARTRIDGE
Parts List
ITEM QTY PART NUMBER DESCRIPTION
1 1 CAC60-0002/3-4 ROLLER
D
2 1 SPH-1252 WAVE WASHER
3 4 BSG-1090 8mm FLANGE BUSHING
4 6 SPH-1276 SNAP RING, 8mm
5 1 BSG-1085 BUSHING 16mm
6 1 CAC60-0167-4 LINK BAR
7 2 SPH-1277 5/16 BRONZE WASHER
8 2 CAC60-0047-3 BUSHING, OILITE
9 1 CAC60-0001/3-6 FRONT ROLLER ARM
10 1 SPR-1044 SPRING, COMPRESSION
11 2 SPH-1339 M8 WASHER
12 4 FBHME012P10 M4 x 12 BUTTON HEAD
13 1 FBHME016P10 BUTTON HEAD M4-1.0 X 16
14 1 FFWMFP FLAT WASHER M5
15 1 FFHMG016P10 FHCS M6 X 1.0 X 16 LG.
16 1 CAC60-0073/3-3 SMALL ROLLER
17 2 BSG-1098 BUSHING
18 1 .FPACAC61 FINGER PLATE ASSY.
19 1 FNLNMEP M4 NYLOCK NUT
C 20 1 FBHME020P10 M4 x 20 PAN HEAD SCREW
21 1 SPR-1055 EXTENSION SPRING
22 1 CAC60-0159-3 SHAFT SUPPPORT LOWER
23 1 CAC60-0111-3 CLEVIS
24 1 SC31 SET COLLAR 5/16
25 1 .SA61A SHAFT ASSEMBLY, 3"
26 7 FFHMF012P10 FHCS M5 X 0.8 X 12 LG.
27 1 CAC60-0141-4 KNIFE GUARD LOCK
28 1 CAC60-0166-4 SLIDING BLOCK, DBL BEARING
29 1 CAC60-0142-3 BUSHING RETAINER
30 1
BSG-1124 10mm LINEAR BEARING
31 10 BRG-2015 10mm FLANGE BEARING
32 1 SPH-1489 19mm EXTERNAL SNAP RING
33 1 CAC60-0158-3 SHAFT SUPPORT UPPPER
34 1 CAC60-0160-3 SHAFT SUPPORT FOR SPACER
35 1 CAC60-0161-3 SPACER
36 1 FFHMF025P10 FHCS M5 X 25 LG.
37 1 CAC60-0164-4 SLIDING BLOCK SUPPORT
38 1 CAC60-0165-3 SHAFT
B
39 1 BSG-1136R1-3 BUSHING, REWORKED
40 1 CAC60-0171/3-4 TAPE GUIDE PLATE 3"
41 1 CAC60-0172/3-4 ROLLER, TAPE GUIDE PLATE
42 2 FFWMHP FLAT WASHER M8
43 1 FSSMF020B10 M5x0.8 20mm LG
44 1 CAC60-0174/3-4 SHAFT, PIVOT EXTENSION
45 1 CAC60-0173/3-3 SHAFT, FRONT ARM SUPPORT
A
4
3
SS MI
SS
SS MI
SS MI
SS
SS
P-S
P-S
P-S
P-S
SS MI
P-S
12
SS
SS
SS
29
SS
SS
P-S
32
SS
SS
SS
P-S
SS MI
37
SS
31
7
SS MI
31
4
P-S
P-S
SS
SS
26
33
26
35
22
34
36 26
3
(PNEUMATIC CARTRIDGE ONLY)
ASSEMBLIES CAN BE PURCHASED
AS ASSEMBLY #'S
.FPACAC61-SB
.FPACAC61SS-SB
.FPACAC61-SBMI
.FPA61-SBSSMI
31
31
11
6
30 31
7
28
16
17
3
4
40
27
12
31
38
25
31
24
8
23
8
PART #
MAT'L
STD
ST. ST.
STAINLESS : NO FINISH
THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF
LOVESHAW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY
INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE
REPRODUCED OTHER THAN FOR YOUR OWN USE OR TO BE DISCLOSED TO OTHER
WITHOUT THE EXPRESSED WRITTEN CONSENT OF LOVESHAW AND WILL BE
RETURNED TO LOVESHAW UPON REQUEST.
2
REV
A
5
10
14
3
31
18
4
3
4
17
26
3
31
31
11
2
4
42
1 41
42
ASSEMBLIES CAN BE PURCHASED
AS ASSEMBLY #'S
.RGPA61/V
.RGPA61SS/V
.RGPA61MI/V
.RGPA61MISS/V
CAD FILE
TOLERANCES UNLESS
OTHERWISE NOTED:
2206 EASTON TPK., SOUTH CANAAN, PA.
PLOT DATE
+ -
.X = .050
- TITLE
1/29/2014
DRAWN DATE
+ 
+
INCH .XX = .015 - -
ANGLES 1/2
-
+
.XXX = .005
DO NOT SCALE PRINT -
+
.X = 1.0mm -
MACH.
+ DWG NO
125
METRIC .XX = .3mm -
FINISH
+
.XXX = .1mm
-
MATERIAL
+ -
FRACTIONS 1/64
DRAWN
2
1
REVISION HISTORY
DESCRIPTION DATE BY
RELEASED 1/29/2014 BJF
D
19
39
9
26
C
15
43
45
13
21
44
20
B
LOVESHAW
A
FRONT ROLLER ARM ASSY
SCALE
CHECKED
BRYCEF
APPROVED
1
