Signode Little David LD16AE 2.0 Operator's Manual page 71

necessary to adjust the stop depending on the type of machine that the
cartridge is being used in. If the cartridge is placed in a machine and the
tape is not being applied to the major flaps with enough pressure an
adjustment will be necessary. This will be evident by inspecting the box
as it exits the machine. Normal symptoms include the tape bridging
across the major flaps, or the tape bunching up on the major flaps after
the tape was cut. Refer to figure 10A & 10B.
Jam nut
Figure 10A
Figure 10B
Recommended 1/16" to
1/8" interference
Front arm
stopper
Box line
