Signode Little David LD16AE 2.0 Operator's Manual page 100

4
1
D
16
15
10
8
C
7
WRAP THIS LEG IN DIRECTION SHOWN.
B
14
4
SPECIAL NOTES:
1) ITEM #16, TORSION SPRING, MUST BE PRELOADED
ONE FULL TURN TO GET THE APPROPRIATE TENSION.
IT MUST BE WOUND IN THE DIRECTION IT'S WRAPPED
IN TO FUNCTION CORRECTLY.
A
2) ITEM #11, OPTIONAL SPRING FOR PROCESSING VOID BOXES.
LOVESHAW #SPR-1042LD. LIGHT DUTY SPRING IS RED
IN COLOR FOR EASY VISUAL IDENTIFICATION.
4
3
16
9
12
4
2
ASSEMBLIES CAN BE PURCHASED
AS ASSEMBLY #'S
(2" ASSEMBLIES)
(3" ASSEMBLIES)
3
5
11
6
3
.KGA60/V
.KGA60SS/V
.KGA60MI/V
.KGA60SSMI/V
.KGA61/V
.KGA61SS/V PART #
MAT'L
.KGA61MI/V
STD
.KGA61SSMI/V
ST. ST.
STAINLESS : NO FINISH
THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF
LOVESHAW-ITW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY
INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE
REPRODUCED OTHER THAN FOR YOUR OWN USE OR TO BE DISCLOSED TO OTHER
WITHOUT THE EXPRESSED WRITTEN CONSENT OF LOVESHAW-ITW AND WILL BE
RETURNED TO LOVESHAW-ITW UPON REQUEST.
2
PARTS FOR .CAC60 2" CARTRIDGE
ITEM QTY PART NUMBER
1 1
CAC60-0125-6
2 1 CAC60-0028-3
3 1 CAC60-0029-5
4 2 BSG-1091
5 1
CAC60-0036-3
6 2 CAC60-0042-3
7 4 SPR-1045
8 1 CAC60-0043-3
9 1 PSC11B60-4M2
9a 1 PSC11A60-4M2
10 1 SPR-1042
11 2 FFHME008P10
12 2 FSSME004P10
* 13 1 CAC60-0078-3
14 1 SPR-1063
13
15 2 FFHMD008P10
16 2 BSG-1135
PARTS FOR .CAC61 3" CARTRIDGE
ITEM QTY PART NUMBER
1 1 CAC60-0125/3-6
2 1 CAC60-0028/3-3
3 1 CAC60-0029/3-5
4 2 BSG-1091
5 1 CAC60-0036-3
6 2 CAC60-0042-3
7 4 SPR-1045
8 1 CAC60-0043/3-3
9 1 PS4117A60-4M2
9a 1 PS4117AN60-4M2 KNIFE BLADE 3", (OPT. COARSE)
10 1 SPR-1042
11 2 FFHME008P10
12 2 FSSME004P10
*
13 1 CAC60-0078/3-3
14 1 SPR-1063
15 2 FFHMDOO8P10
16 2 BSG-1135
*
USE DEVCON 5 MINUTE EPOXY OR EQUIVALENT
TO AFFIX FELT PAD TO KNIFE GUARD.
KNIFE ASSY.idw
CAD FILE
TOLERANCES UNLESS
OTHERWISE NOTED:
PLOT DATE
+ -
.X = .050
- TITLE
5/17/2011
DRAWN DATE
+ 
+
INCH .XX = .015 - -
ANGLES 1/2
-
+
.XXX = .005
DO NOT SCALE PRINT -
+
.X = 1.0mm -
MACH.
+ DWG NO
125
METRIC .XX = .3mm -
FINISH
+
.XXX = .1mm
-
MATERIAL
+ -
FRACTIONS 1/64
DRAWN
2
1
REVISION HISTORY
REV DESCRIPTION DATE BY
A RELEASED 5/17/2011 BJF
D
Parts List
DESCRIPTION SS MI
KNIFE ARM, DBL. MI
SS
KNIFE GUARD PIVOT PIN SS
KNIFE GUARD SS MI
BUSHING, 6mm
MI
TAB ADJUSTER SS
PIN
SPRING SS
PIN PLATE SS
KNIFE BLADE 2"
KNIFE BLADE 2" , (OPT. COARSE)
EXTENSION SPRING
M4 X 8 FHCS P-S
M4 x 4 CUP POINT SET SCREW P-S
C
KNIFE GUARD CUSHION
TORSION SPRING MI
M3 X 8 FHCS P-S
BRONZE WASHER
Parts List
DESCRIPTION SS MI
KNIFE ARM, DBL.
SS MI
KNIFE GUARD PIVOT PIN SS
KNIFE GUARD SS MI
BUSHING, 6mm
TAB ADJUSTER SS MI
PIN
SPRING SS
PIN PLATE SS B
KNIFE BLADE 3"
EXTENSION SPRING
M4 x 8 FHCS P-S
M4 x 4 CUP POINT SET SCREW P-S
KNIFE GUARD CUSHION
TORSION SPRING MI
M3 x 8 FHCS P-S
BRONZE WASHER
LOVESHAW
A
an ITW Company
RT. 296, SOUTH CANAAN, PA.
KINFE ASSEMBLY .CAC60/61
KNIFE ASSY-PTA
SCALE
CHECKED
BRYCEF
APPROVED
1
