MONTHLY MAINTENANCE

DEVICE
BEARINGS: HEAD LIFTING LINEAR BEARINGS
FLANGED BEARINGS
SPROCKETS
CHAINS – HEAD LIFTING AND DRIVE CHAINS.
INFEED BELT
MAIN DRIVE REDUCER
COMPRESSED AIR FILTER AND BOWL.
CHECK OIL CUPS ON LINEAR HEAD LIFTING
BEARINGS. IF NECESSARY FILL OIL CUPS TO
TOP WITH MEDIUM WEIGHT GENERAL PURPOSE
OIL
LUBRICATE ALL FLANGE BEARINGS IF
NECESSARY WITH MULTI PURPOSE BEARING
GREASE. FLANGE BEARINGS ARE FITTED WITH
ZERK FITTINGS.
LUBRICATE ALL SPROCKETS WITH ZERK
FITTINGS IF NECESSARY.
CHECK HEAD LIFTING AND DRIVE CHAINS FOR
PROPER TENSION. CHAINS SHOULD NOT BE
LOOSE OR SAGGING.
CHECK INFEED BELT FOR FRAYING OR EXCESS
WEAR. CHECK THAT BELT LACING IS NOT
PULLING APART. CHANGE BELT IF
NECESSARY.
CHECK THE LEVEL OF LUBRICANT IN
REDUCER. REMOVE BREATHER AND REDUCER
PLUG DIRECTLY ABOVE HEIGHT OF OUTPUT
SHAFT. FILL REDUCER WITH MOBIL 634
SYNTHETIC OIL THROUGH BREATHER HOLE
UNTIL OIL LEVEL REACHES THE HEIGHT OF
THE UNPLUGGED LOWER HOLE.
EMPTY THE FILTER BOWL OF COLLECTED
LIQUID IMPURITIES, SUCH AS WATER AND OIL.
VISUALLY CHECK FILTER MATERIAL FOR
BUILD UP OF SOLID IMPURITIES. IF NECESSARY
CHANGE FILTER. NEVER ALLOW FILTER AND
BOWL TO BECOME OVERRUN WITH
CONTAMINANTS. THESE CONTAMINANTS WILL
MAKE THEIR WAY TO THE CYLINDERS AND
SOLENOIDS VALVE AND WILL CAUSE HAVOC.
Page | 27
ACTION
