IMPORTANT - DO NOT DESTROY THIS MANUAL. It is the customer's responsibility to have all operators
and service personnel read and understand this manual. Contact your local Signode representative for
additional copies of this manual.
YC MANUAL SEALER
YC-1223 (Part No. 023850)
YC-5823 (Part No. 023858)
YC-1-3425 (Part No. 023875)
TOOL SPECIFICATIONS
STRAP
WIDTH
1/2" (12.7mm)
5/8" (15.8mm)
3/4" (19mm)
Signode tools and machines are designed and warranted to work together with
Signode strapping and seals. Use of non-Signode strap and seals and/or
manufactured or specified replacement parts may result in strap breakage or
joint separation while applying strapping to a load or during normal shipping
and handling. This could result in severe personal injury.
© Copyright 2000, Signode 186042 Rev. 10/2000
THICKNESS
UP TO .023" (0.58mm)
UP TO .025" (0.63mm)
SEALS
REQUIRED
SEALING
TYPE
OPERATIONS
12C
58C
1
34C
Advertisement
Related Manuals for Signode YC Series
Summary of Contents for Signode YC Series
- Page 1 This could result in severe personal injury. IMPORTANT - DO NOT DESTROY THIS MANUAL. It is the customer's responsibility to have all operators and service personnel read and understand this manual. Contact your local Signode representative for additional copies of this manual.
- Page 2 TRAINING This tool must not be used by persons not properly trained in its use. Be certain that you receive proper training from your employer. If you have any questions contact your Signode Representative. EYE INJURY HAZARD Failure to wear safety glasses with side shields NOTE: NOTCHES MUST BE EQUALLY SPACED ALONG THE can result in severe eye injury or blindness.
- Page 3 Stand to one side of the strap while tensioning. Make sure all bystanders are clear before proceeding. Failure to follow the above could result in serious personal injury. Using an approved Signode strap tensioner, encircle the package with strap and tension as required per the tensioner's instructions.
- Page 4 PARTS LIST, PART NO. PART NO. PART NO. QTY. YC-1223 YC-5823 YC-1-3425 DESCRIPTION 008648 008648 008648 Knob 023854 023854 023854 Upper handle 023863 023863 023863 Link pin 023860 023860 023860 Long link 023855 023856 023856 023861 023861 023861 Short link 023862 023859 023857...
