Boxes jamming in machine:

1. Jam clearing procedure:
A. Stop machine.
B. Open safety gates and raise head.
C. Remove box. Rethread and cut tape flush with end of the roller .
D. Close safety gates.
E. Press "start" button.
2. Incorrect box size or shape:
A. Check boxes to make sure the size falls within the minimum / maximum limits of
the machine.
B. Machine will not process unstable boxes.
3. Contents bulging through top of box:
A. Check to be sure that the box is not overfilled with contents.
4. Box slipping against belts:
A. Increase the down pressure by adjusting the front suppressor.
5. Head pressure too high:
A. Raise head slightly. Adjust front suppressor height.

Belt drive problems:

1. Belts do not move:
A. Check that machine is connected to a live electrical circuit.
2. Belts slip:
A. Check tension of belts and adjust idler rollers.
3. Box slips against belts:
A. Increase tension on belt drive system.
