Signode Little David LD16AE 2.0 Operator's Manual page 89

4
Parts List
ITEM QTY PART NUMBER DESCRIPTION
1 1 CAC60-0002/3-4 ROLLER
2 1 SPH-1252 WAVE WASHER
3 4 BSG-1090 8mm FLANGE BUSHING
4 4 SPH-1276 SNAP RING, 8mm
D
5 1 BSG-1085 BUSHING 16mm
6 1 CAC60-0007-5 LINK BAR
7 1 CAC60-0001/3-6 FRONT ROLLER ARM
8 1 SPR-1044 SPRING, COMPRESSION
9 2 SPH-1339 M8 WASHER
10 1 FBHME016P10 BUTTON HEAD M4-1.0 X 16
11 1 FFWMFP FLAT WASHER M5
12 1 FFHMG016P10 FHCS M6 X 1.0 X 16 LG.
13 1 CAC60-0073/3-3 SMALL ROLLER
14 2 BSG-1098 BUSHING
15 1 .FPACAC61 FINGER PLATE
16 1 FNLNMEP M4 NYLOCK NUT
17 1 FBHME020P10 M4 x 20 PAN HEAD SCREW
18 1 SPR-1055 EXTENSION SPRING
19 1 CAC60-0159-3 SHAFT SUPPPORT LOWER
20 1 .SA61A SHAFT ASSEMBLY, 3"
21 5 FFHMF012P10 FHCS M5 X 0.8 X 12 LG.
22 4 BRG-2015 10mm FLANGE BEARING
23 1
C CAC60-0158-3 SHAFT SUPPORT UPPPER
24 1 CAC60-0160-3 SHAFT SUPPORT FOR SPACER
25 1 CAC60-0161-3 SPACER
26 1 FFHMF025P10 FHCS M5 X 25 LG.
27 1 BSG-1136R1-3 BUSHING, REWORKED
28 1 CAC60-0171/3-4 TAPE GUIDE PLATE 3"
29 1 CAC60-0172/3-4 ROLLER, TAPE GUIDE PLATE
30 2 FFWMHP FLAT WASHER M8
31 1 CAC60-0144-4 KNIFE GUARD LOCK, FIXED
32 2 FHHMF010P10 HHCS M5 X 0.8 X 10 LG.
33 2 FLWMFP LOCK WASHER M5
34 1 FSSMF020B10 M5x0.8 20mm LG
35 1 CAC60-0174/3-4 SHAFT, PIVOT EXTENSION
36 1 CAC60-0173/3-3 SHAFT, FRONT ARM SUPPORT
B
(3" STD CAC61 ONLY)
A
4
3
SS MI
SS
ASSEMBLIES CAN BE PURCHASED
SS MI
SS MI
SS
SS
P-S
P-S
P-S
SS MI
22
P-S
9
SS
SS
SS
P-S
SS
SS
SS
P-S
SS MI
33
P-S 32
MI
P-S
P-S
B-S
SS
SS
14
4
23
21
24
4
19
21
25
21
26
20
3
2
AS ASSEMBLY #'S
.FPACAC61-SB
.FPACAC61SS-SB
.FPACAC61-SBMI
.FPA61-SBSSMI
22
8
6
3
31
4
13
14
3
22
9
4
28
3
30
1
FRONT ROLLER ARM ASSY (STD) 2.0.idw
PART # CAD FILE
MAT'L
STD
PLOT DATE
1/28/2016
ST. ST. DRAWN DATE
DO NOT SCALE PRINT
STAINLESS : NO FINISH
THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF
LOVESHAW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY
INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE
REPRODUCED OTHER THAN FOR YOUR OWN USE OR TO BE DISCLOSED TO OTHER
WITHOUT THE EXPRESSED WRITTEN CONSENT OF LOVESHAW AND WILL BE
RETURNED TO LOVESHAW UPON REQUEST.
2
7
16
5
11
3
15
36
10
34
35
22
ASSEMBLY CAN BE PURCHASED
AS ASSEMBLY #'S
.RGPA61/V
.RGPA61SS/V
.RGPA61MI/V
.RGPA61MISS/V
30
29
LOVESHAW
TOLERANCES UNLESS
OTHERWISE NOTED:
2206 EASTON TPK., SOUTH CANAAN, PA.
+ -
.X = .050
- TITLE
+ 
+
INCH .XX = .015 - - FRONT ROLLER ARM ASSY
ANGLES 1/2
-
+
.XXX = .005
-
+
.X = 1.0mm -
MACH.
FRONT ROLLER ARM ASSY (STD) 2.0.2
+ DWG NO
125
METRIC .XX = .3mm -
FINISH
+
.XXX = .1mm
-
MATERIAL
+ -
FRACTIONS 1/64
BRYCEF
DRAWN
1
D
27
21
12
C
17
2
18
B
A
SCALE
CHECKED
APPROVED
1
