Signode Little David LD16AE 2.0 Operator's Manual page 91

4
Parts List
ITEM QTY PART NUMBER DESCRIPTION
1 1 CAC60-0002/3-4 ROLLER
2 1 CAC60-0171/3-4 TAPE GUIDE PLATE 3"
3 1 SPH-1252 WAVE WASHER
4 4
BSG-1090 8mm FLANGE BUSHING
D
5 6 SPH-1276 SNAP RING, 8mm
6 1 BSG-1085 BUSHING 16mm
7 1 CAC60-0001/3-6 FRONT ROLLER ARM
8 1 SPR-1044 SPRING, COMPRESSION
9 1 FFWMFP FLAT WASHER M5
10 1 FFHMG016P10 FHCS M6 X 1.0 X 16 LG.
11 1 CAC60-0073/3-3 SMALL ROLLER
12 2 BSG-1098 BUSHING
13 1 .FPACAC61 FINGER PLATE
14 1 FNLNMEP M4 NYLOCK NUT
15 1 FBHME020P10 M4 x 20 PAN HEAD SCREW
16 1 SPR-1055 EXTENSION SPRING
17 1 .SA61A SHAFT ASSEMBLY, 3"
18 1 FBHME016P10 BUTTON HEAD M4-1.0 X 16
19 1 BSG-1136R1-3 BUSHING, REWORKED
20 1 CAC60-0167-4 LINK BAR
21 2 SPH-1277 5/16 BRONZE WASHER
22 2 SPH-1339 M8 WASHER
23 1 CAC60-0159-3 SHAFT SUPPPORT LOWER
C
24 7 FFHMF012P10 FHCS M5 X 0.8 X 12 LG.
25 4 FBHME012P10 M4 x 12 BUTTON HEAD
26 1 CAC60-0141-4 KNIFE GUARD LOCK
27 1 CAC60-0166-4 SLIDING BLOCK, DBL BEARING
28 1 CAC60-0142-3 BUSHING RETAINER
29 1 BSG-1124 10mm LINEAR BEARING
30 10 BRG-2015 10mm FLANGE BEARING
31 1 SPH-1489 19mm EXTERNAL SNAP RING
32 1 CAC60-0158-3 SHAFT SUPPORT UPPPER
33 1 CAC60-0160-3 SHAFT SUPPORT FOR SPACER
34 1 CAC60-0161-3 SPACER
35 1 FFHMF025P10 FHCS M5 X 25 LG.
36 1 CAC60-0164-4 SLIDING BLOCK SUPPORT
37 1 CAC60-0165-3 SHAFT
38 1
CAC60-0173/3-3 SHAFT, FRONT ARM SUPPORT
39 1 CAC60-0174/3-4 SHAFT, PIVOT EXTENSION
40 1 FSSMF020B10 M5x0.8 20mm LG
41 1 CAC60-0172/3-4 ROLLER, TAPE GUIDE PLATE
42 2 FFWMHP
FLAT WASHER M8
B
A
(3" HS CAC61 ONLY)
4
3
SS MI
SS MI
SS
SS MI
SS
P-S
P-S
SS MI
P-S
SS
SS MI
P-S
SS MI
22
SS
P-S
P-S
25
28
SS
SS
SS
SS
P-S
27
SS MI
SS
30 21
SS
SS
B-S
36
SS MI
26
P-S 30
5
32
24
24
24
23
35
33
34 24
3
2
ASSEMBLIES CAN BE PURCHASED
AS ASSEMBLY #'S
.FPACAC61-SB
.FPACAC61SS-SB
.FPACAC61-SBMI
.FPA61-SBSSMI
30
30
20
30
31
30
29
21
11 12
4
5
12
2
4
25
30
1
17
PART # CAD FILE
MAT'L
STD
PLOT DATE
ST. ST. DRAWN DATE
DO NOT SCALE PRINT
STAINLESS : NO FINISH
THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF
LOVESHAW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY
INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE
REPRODUCED OTHER THAN FOR YOUR OWN USE OR TO BE DISCLOSED TO OTHER
WITHOUT THE EXPRESSED WRITTEN CONSENT OF LOVESHAW AND WILL BE
RETURNED TO LOVESHAW UPON REQUEST.
2
14
6
8
9
4
13
5
4
38
5
18
40
30
24
39
30
22
37
5
42
41
42
ASSEMBLIES CAN BE PURCHASED
AS ASSEMBLY #'S
.RGPA61/V
.RGPA61SS/V
.RGPA61MI/V
.RGPA61MISS/VI
LOVESHAW
TOLERANCES UNLESS
OTHERWISE NOTED:
2206 EASTON TPK., SOUTH CANAAN, PA.
+ -
.X = .050
- TITLE
1/11/2016
+ 
+
INCH .XX = .015 - - FRONT ROLLER ARM ASSY
ANGLES 1/2
-
+
.XXX = .005
-
+
.X = 1.0mm -
MACH.
+ DWG NO
125
METRIC .XX = .3mm -
FINISH
+
.XXX = .1mm
-
MATERIAL
+ -
FRACTIONS 1/64
BRYCEF
DRAWN
1
D
19
7
24
10
C
15
3
16
B
A
SCALE
CHECKED
APPROVED
1
