Step 1: Box enters the machine
A. (1) Limit switch LD-1 is depressed.
B. (2) SV-1 is de-energized.
Step 2: Box depresses limit switch LS-2
No action
Step 3: Box releases LS-1 (LS-2 is still depressed)
A. (1) Kicker solenoid valve SV-2 is activated.
Step 4: Box releases LS-2
A. (1) Gate cylinder solenoid valve SV-2 is Energized Bringing down the gate.
The safety gate switches, LS-3 to LS-6 de-activate the "E"-Stop circuit by
opening any one of the four safety gates. This will stop the machine and de-activate
the main air dump valve. To re-start the machine, safety gates must first be close and
the "E"-Stop push button must be fully extended, then the "Star" push button on the
control station is pressed.

Shut-Down Procedure

Control Stop:

1) Turn selector switch to test position. Wait until machine finishes processing box.
2) Depress emergency stop push button.

Emergency Stop:

1) Depress emergency stop push button.
2) Remove any unmade or jammed boxes before restarting machine.
Kicker valve brings up kicker up.
Gate cylinder solenoid valve SV-2 is de-energized brining gate up.
Kicker comes down.
Gate is still up.
