IMPORTANT - DO NOT DESTROY THIS MANUAL. It is the customer's responsibility to have all operators

and service personnel read and understand this manual. Contact your local Signode representative for

additional copies of this manual.

SRC-TYPE MANUAL SEALER

SRC-3820 (Part No. 008620)

SRC-1223 (Part No. 008625)

SRC-5823 (Part No. 008630)

SRC-3423 (Part No. 008635)

TOOL SPECIFICATIONS

STRAP

WIDTH

3/8" (9.5mm)

1/2" (12.7mm)

5/8" (15.8mm)

3/4" (19mm)

Signode tools and machines are designed and warranted to work together with

Signode strapping and seals. Use of non-Signode strap and seals and/or

manufactured or specified replacement parts may result in strap breakage or

joint separation while applying strapping to a load or during normal shipping

and handling. This could result in severe personal injury.

THICKNESS

UP TO .020" (0.50mm)

UP TO .023"(0.58mm

SEALS

REQUIRED

SEALING

TYPE

OPERATIONS

38SPC

12SPC

58SPC

34SPC
