Signode Little David LD16AE 2.0 Operator's Manual page 84

4
D
C
B
2
A
4
3
3
1
3
2
4
ITEM QTY
1
2
3
4
5
6
5 7
7
ITEM QTY PART NUMBER
1
2
3
4
5
6
7
(TOP LOAD BRACKET REQUIRED FOR CAC60/61X CARTRDIGES)
(FOR USE IN LDXRTB & LDXUTB MACHINES ONLY)
MAIN ASSY HS 2.0.idw
PART # CAD FILE
MAT'L TOLERANCES UNLESS
OTHERWISE NOTED:
STD
PLOT DATE
.X
7/27/2011
ST. ST. DRAWN DATE
INCH .XX
.XXX
DO NOT SCALE PRINT
STAINLESS : NO FINISH
THIS DRAWING AND SUBJECT MATTER THEREON IS THE EXCLUSIVE PROPERTY OF
METRIC
LOVESHAW-ITW AND IS TO BE TREATED BY YOU AS CONFIDENTIAL PRPRIETARY
INFORMATION. THIS DRAWING OR SUBJECT MATTER THEROF SHALL NOT BE
REPRODUCED OTHER THAN FOR YOUR OWN USE OR TO BE DISCLOSED TO OTHER
WITHOUT THE EXPRESSED WRITTEN CONSENT OF LOVESHAW-ITW AND WILL BE
FRACTIONS
RETURNED TO LOVESHAW-ITW UPON REQUEST.
2
1
REVISION HISTORY
REV DESCRIPTION DATE
A RELEASED 7/27/2011
PARTS FOR .CAC60 2" CATRIDGE
Parts List
PART NUMBER DESCRIPTION
1 .FRACAC60-2 FORNT ROLLER ARM ASSEMBLY
1
.RRACAC60-2 REAR ROLLER ARM ASSEMBLY
1 .KAACAC60 KNIFE ASSEMBLY
1 .TCA2 TAPE CORE ASSEMBLY 2"
1 .TRA60A TENSION ROLLER ASSEMBLY
1
CAC60-0154/2-4 TOP LOAD BRACKET, 2"
1 .RA-60 ROLLER ASSEMBLY
PARTS FOR .CAC61 3" CARTRIDGE
Parts List
DESCRIPTION
1 .FRACAC61-2 FRONT ROLLER ARM ASSEMBLY
1 .RRACAC61-2 REAR ROLLER ARM ASSEMBLY
1 .KAACAC61 KINIFE ASSEMBLY
1 .TCA3 TAPE CORE ASSEMBLY 3"
1 .TRAC61A TENSION ROLLER ASSEMBLY
1 CAC60-0154-4 TOP LOAD BRACKET 3"
1 .RA-61 ROLLER ASSEMBLY, 3"
LOVESHAW
an ITW
RT. 296, SOUTH CANAAN, PA.
+ -
= .050
- TITLE
+ 
+
= .015 - - MAIN ASSEMBLY
ANGLES 1/2
-
+
= .005
-
+
.X = 1.0mm -
MACH.
MAIN ASSY HS 2.0
+ DWG NO SCALE
125
.XX = .3mm -
FINISH
+
.XXX = .1mm
-
CHECKED
MATERIAL
+ -
1/64
BRYCEF
DRAWN APPROVED
1
BY
BJF
D
SS MI
SS MI
MI
SS
SS MI
SS
SS MI
C
SS MI
SS MI
SS MI
SS MI
SS
SS MI
SS
B
A
