Machine Preperation

Elevations for conveyor rollers and stripper plate. Gate roller in "down" position & belt
should provide a smooth box flow into the machine.

Box Preparation

Note: Major flaps should not be inside minor flaps or bent outward far enough to
miss the flap folders. Minor flaps should be vertical or slightly inwards in the case of double wall
boxes. Minor flap score lines must be broken.
Conveyor Alignment
IMPORTANT
