Box does not enter machine:

A. Check mounting height of infeed conveyor. Top of infeed conveyor roller must be
in-line with infeed gate roller when gate is down.
B. Check that gate is "down". If necessary, check pneumatic circuit.

Front suppressor does not compress properly:

A. Check sensing height.
B. Adjust head height properly.

Taping head adjustment malfunction:

A. Check the chains on both idler sprockets on both sides of machine.
B. Check that drive wheel is tight on shaft.

Taping head crushes box:

A. Check head height, adjust if necessary.

Kicker does not close rear flap:

A. Check if kicker closes too early or too late - adjust accordingly.
B. Check switch arm adjustment.
