6.7. RF Receiving Sensitivity

The following tables show conducted RF min. receiving sensitivity of EM120R-GL and EM160R-GL.
Table 40: EM120R-GL&EM160R-GL Conducted RF Min. Receiving Sensitivity
Frequency Primary
WCDMA B1 -111
WCDMA B2 -109.5
WCDMA B3 -109.5
WCDMA B4 TBD
WCDMA B5 -111
WCDMA B6 TBD
WCDMA B8 -111.5
WCDMA B19 TBD
LTE-FDD B1 (10 MHz) -98
LTE-FDD B2 (10 MHz) -97.8
LTE-FDD B3 (10 MHz) -98.8
LTE-FDD B4 (10 MHz) -97.7
LTE-FDD B5 (10 MHz) -99.7
LTE-FDD B7 (10 MHz) -96
LTE-FDD B8 (10 MHz) -99
LTE-FDD B12 (10 MHz) -99.8
LTE-FDD B13 (10 MHz) -100.2
LTE-FDD B14 (10 MHz) -99.2
LTE-FDD B17 (10 MHz) -99.9
LTE-FDD B18 (10 MHz) -99.6
EM120R-GL&EM160R-GL_Hardware_Design
EM120R-GL&EM160R-GL Hardware Design
Diversity SIMO 1)
-110 -110.5
-110 -110
-110.5 -111
TBD TBD
-111 -112
TBD TBD
-110.5 -111
TBD TBD
-98 -100.7
-97.7 -100.3
-97.3 -100.8
-97.9 -100.6
-99 -102
-97.2 -99.4
-99.2 -101.7
-99.5 -102.3
-99.4 -102.5
-99.2 -101.8
-99.6 -102.3
-99.4 -102.2
LTE-A Module Series
SIMO 2) (Worst Case)
-106.7 dBm
-104.7 dBm
-103.7 dBm
-106.7 dBm
-104.7 dBm
-106.7 dBm
-103.7 dBm
-106.7 dBm
-96.3 dBm
-94.3 dBm
-93.3 dBm
-96.3 dBm
-94.3 dBm
-94.3 dBm
-93.3 dBm
-93.3 dBm
-93.3 dBm
-93.3 dBm
-93.3 dBm
-96.3 dBm
