Quectel LTE-A Module Series Hardware Design page 23

67 RESET# RESET#
68 SUSCLK (32kHz) ANT_CONFIG
69 CONFIG_1 CONFIG_1
70 3.3V VCC
71 GND GND
72 3.3V VCC
73 GND GND
74 3.3V VCC
75 CONFIG_2 CONFIG_2
NOTE
Please keep all NC, reserved and unused pins unconnected.
EM120R-GL&EM160R-GL_Hardware_Design
LTE-A Module Series
EM120R-GL&EM160R-GL Hardware Design
WWAN reset input
DI
Active low.
DI Antenna configuration
Connected to GND
internally
PI Power supply
Ground
PI Power supply
Ground
PI Power supply
NC
domain.
Pulled up
internally.
1.8 V power
domain.
Pulled up
internally.
1.8 V power
domain.
Vmin = 3.135 V
Vnorm = 3.7 V
Vmax = 4.4 V
Vmin = 3.135 V
Vnorm = 3.7 V
Vmax = 4.4 V
Vmin = 3.135 V
Vnorm = 3.7 V
Vmax = 4.4 V
22 / 79
