Product Concept

2.1. General Description

EM120R-GL&EM160R-GL are LTE-A/UMTS/HSPA+ wireless communication modules with receive
diversity. It provides data connectivity on LTE-FDD, LTE-TDD, DC-HSDPA, HSPA+, HSDPA, HSUPA
and WCDMA networks with standard PCI Express M.2 interface.
It supports embedded operating systems such as Windows, Linux and Android, and provides GNSS
to meet customers' specific application demands.
and voice functionality 2)
The following table shows the frequency bands and GNSS types of EM120R-GL&EM160R-GL.
Table 1: Frequency Bands and GNSS Types of EM120R-GL&EM160R-GL
Mode
LTE-FDD
(with Rx-diversity/MIMO 5) )
LTE-TDD
5)
(with Rx-diversity/MIMO )
WCDMA
(with Rx-diversity)
GNSS 1)
NOTES
1. 1) GNSS function is optional.
2. 2) EM120R-GL&EM160R-GL contain Telematics version and Data-only version. Telematics
version supports voice and data functions, while Data-only version only supports data function.
3)
3. LTE-FDD B29/B32 and LTE-TDD B46 support Rx only and are only for secondary component
EM120R-GL&EM160R-GL_Hardware_Design
EM120R-GL&EM160R-GL Hardware Design
EM120R-GL&EM160R-GL
B1 4) /B2 4) /B3 4) /B4 4) /B5/B7 4) /
B8/B12/B13/B14/B17/B18/B19/B20/B25
B29 3) /B30 4) /B32 3) 4) /B66 4)
B38 4) /B39 4) /B40 4) /B41 4) /B42/B43/B46
B1/B2/B3/B4/B5/B6/B8/B19
GPS;
GLONASS;
BeiDou/Compass;
Galileo
LTE-A Module Series
1)
4)
/B26/B28/
3) /B48
