7.6. RF Receiving Sensitivity

The following table shows the conducted RF receiving sensitivity of SC650T module.
Table 48: SC650T-NA RF Receiving Sensitivity x`
Frequency
LTE-FDD B2 (10M)
LTE-FDD B4 (10M)
LTE-FDD B5 (10M)
LTE-FDD B7 (10M)
LTE-FDD B12 (10M)
LTE-FDD B13 (10M)
LTE-FDD B14 (10M)
LTE-FDD B25 (10M)
LTE-FDD B26 (10M)
LTE-FDD B66 (10M)
Table 49: SC650T-EM RF Receiving Sensitivity
Frequency
SC650T_Hardware_Design
23dBm± 2dB
23dBm± 2dB
23dBm± 2dB
Receive Sensitivity (Typ.)
Primary
-99.5dBm -100.4dBm
-98.7dBm -99.6dBm
-100.3dBm -99.7dBm
-96dBm -99.2dBm
-100dBm -100.1dBm
-98.5dBm -100.3dBm
-98.9dBm -101dBm
-99.4dBm -100.4dBm
-100.5dBm -99.5dBm
-98.3dBm -99.4dBm
Receive Sensitivity (Typ.)
Primary Diversity
<-39dBm
<-39dBm
<-39dBm
Diversity SIMO
-102.9dBm
-102.3dBm
-103.6dBm
-100dBm
-103.2dBm
-102.6dBm
-102.9dBm
-102.8dBm
-103.9dBm
-102dBm
SIMO
Smart LTE Module Series
SC650T Hardware Design
3GPP (SIMO)
-94.3dBm
-96.3dBm
-94.3dBm
-94.3dBm
-93.3dBm
-93.3dBm
-93.3dBm
-92.8dBm
-93.8dBm
-95.8dBm
3GPP (SIMO)
