3.12. Antenna Tuner Control Interfaces*
ANTCTL [0:3] and RFFE signals are used for antenna tuner control and should be routed to an
appropriate antenna control circuit. More details about the interface will be added in a future version of the
document.
3.12.1. Antenna Tuner Control Interface through GPIOs
Table 23: Pin Definition of Antenna Tuner Control Interface through GPIOs
Pin Name
Pin No.
I/O
ANTCTL0
59
DO
ANTCTL1
61
DO
ANTCTL2
63
DO
ANTCTL3
65
DO
3.12.2. Antenna Tuner Control Interface through RFFE
Table 24: Pin Definition of Antenna Tuner Control Interface through RFFE
Pin Name
Pin No.
I/O
RFFE_CLK
56
DO
RFFE_DATA
58
IO
NOTE
"*" means under development.
EM120R-GL&EM160R-GL_Hardware_Design
EM120R-GL&EM160R-GL Hardware Design
Description
Antenna tuner control
Antenna tuner control
Antenna tuner control
Antenna tuner control
Description
RFFE serial interface used for
external tuner control
LTE-A Module Series
Comment
1.8 V power domain
1.8 V power domain
1.8 V power domain
1.8 V power domain
Comment
If unused, keep it open.
If unused, keep it open.
51 / 79
