W_Disable2# Signal - Quectel LTE-A Module Series Hardware Design

Table 16: RF Function Status
W_DISABLE1# Level AT Commands
High Level AT+CFUN=1
AT+CFUN=0
High Level
AT+CFUN=4
AT+CFUN=0
Low Level AT+CFUN=1
AT+CFUN=4

3.10.2. W_DISABLE2# Signal

EM120R-GL&EM160R-GL provide a W_DISABLE2# pin to disable or enable the GNSS function. The
W_DISABLE2# pin is pulled up by default. Driving it to low level will disable the GNSS function. The
combination of W_DISABLE2# pin and AT commands can control the GNSS function.
Table 17: GNSS Function Status
W_DISABLE2# Level AT Commands
High Level AT+QGPS=1
High Level AT+QGPSEND
Low Level AT+QGPS=1
Low Level AT+QGPSEND
EM120R-GL&EM160R-GL_Hardware_Design
LTE-A Module Series
EM120R-GL&EM160R-GL Hardware Design
RF Function Status
Enabled
Disabled
Disabled
GNSS Function Status
Enabled
Disabled
46 / 79
