Quectel LTE-A Module Series Hardware Design page 81

FCC KDB996369 D03v01 Requirements
List of applicable FCC rules
FCC Part 15 Subpart B, Part 22 Subpart H, Part 24 Subpart E, Part 27 Subpart D & L & H & F
& M & N, Part 90 Subpart R & S, Part 96
Summarize the specific operational use conditions
Not Applicable
Limited module procedures
Not Applicable
Trace antenna designs
Refer to Manual Section 4
RF exposure considerations
Refer to FCC certification requirements
Antennas
Technology
WCDMA & LTE Band 2
WCDMA & LTE Band 4
WCDMA & LTE Band 5
LTE Band 7
LTE Band 12
LTE Band 13
LTE Band 14
LTE Band 25
LTE Band 26
LTE Band 30
LTE Band 38
LTE Band 41
LTE Band 48
LTE Band 66
Label and compliance information
Refer to FCC Label
Information on test modes and additional testing requirements
Not Applicable
Frequency Range
(MHz)
1850 ~ 1910
1710 ~ 1755
824 ~ 849
2500 ~ 2570
699 ~ 716
777 ~ 787
788 ~ 798
1850 ~ 1915
814 ~ 849
2305 ~ 2315
2570 ~ 2620
2496 ~ 2690
3550 ~ 3700
1710 ~ 1780
Antenna Type Max Peak Gain (dBi)
Dipole
1.15
-0.50
1.85
1.32
-2.43
-0.10
2.40
1.15
1.85
-3.64
0.93
0.93
-3.37
-0.50
