Product Concept

2.1. General Description

UC20 is an embedded HSPA+/EDGE engine with Rx-diversity. Its UMTS-based modem provides data
connectivity on HSPA+, HSDPA, HSUPA, WCDMA, EDGE, GPRS networks. It can also provide
GPS/GLONASS and voice functionality
of 14.4Mbps on downlink and 5.76Mbps on uplink in HSPA+/HSPA mode. UC20 also support
GPRS/EDGE multi-slot class 12. GPRS supports the coding schemes CS-1, CS-2, CS-3 and CS-4.
EDGE supports CS1-4 and MCS1-9 coding schemes. UC20 contains three variants UC20-A, UC20-E
and UC20-G. You can choose the dedicated type based on the wireless network configuration. The
following table shows the entire radio band configuration of UC20 series.
Table 1: UC20 Series Frequency Bands
GSM
Module
850
UC20-A

UC20-E

UC20-G
NOTE
1)
. UC20 series (UC20-A/UC20-E/UC20-G) includes Data-only and Telematics versions. Data-only
version does not support voice function, Telematics version supports it.
More details about GPRS/EDGE multi-slot configuration and coding schemes, please refer to Appendix B,
C and D.
With a tiny profile of 32.0mm × 29.0mm × 2.5mm, UC20 can meet almost all requirements for M2M
application such as automotive, metering, tracking system, security solutions, routers, wireless POS,
mobile computing devices, PDA phone and tablet PC, etc..
UC20_Hardware_Design
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
1)
for your specific application. UC20 offers a maximum data rate
EGSM DCS PCS UMTS
900 1800 1900 800
  
  
UMTS UMTS
850 900


  
Confidential / Released
UMTS/HSPA Module Series
UC20 Hardware Design
UMTS UMTS Rx-
1900 2100 diversity
 
 
  
GNSS



