Product Concept

2.1. General Description

SA800U-WF is a smart module based on Qualcomm platform and Android operating system, which
provides industrial grade performance. Its general features are listed below:

Support short-range wireless communication via Wi-Fi 802.11a/b/g/n/ac and BT 5.0

Support multiple audio and video codecs

Built-in high performance Adreno

Dedicated low-power Snapdragon sensor core DSP to support always-on use cases

Provide multiple audio and video input/output interfaces as well as abundant GPIO interfaces
The following table shows the supported frequency bands of the module.
Table 1: SA800U-WF Frequency Bands
Type
802.11a/b/g/n/ac
BT 5.0
FM*
SA800U-WF is a 396-pin module, which supports B2B connection. With a compact profile of 60.0 mm ×
37.0 mm × 6.55 mm, the module can meet almost all requirements for M2M applications such as smart
meeting, smart home, security, routers, AR glasses, mobile computing devices, PDA phone, tablet PC,
etc.
NOTE
"*" means under development.
SA800U-WF_Hardware_Design
TM
630 graphics processing unit
Frequency Bands
2402–2482 MHz
5180–5825 MHz
2402–2480 MHz
76–108 MHz
