GAUGE TEMPERATURE

To view the gauge temperature, press the 〈Gauge Temperature〉
button on the Gauge Status Menu (see Figure 3–18). The PDA
displays the gauge temperature both in degrees Fahrenheit and in
degrees Celsius. Press the 〈Done〉 button to return to the Gauge
Status Menu.

BATTERY STATUS

To view the current status of the gauge's NiMH batteries, press the
〈Battery Status〉 button on the Gauge Status Menu (see Figure
3–18). The software displays the status of the batteries, as shown in
Figure 3–10 on page 3–17. This display includes the charger status
(ON or OFF), the actual battery voltage, and the battery status (OK
or LOW). Press the 〈Done〉 button to return to the Gauge Status
Menu.
If the battery voltage falls below 5.5 V, the gauge shuts
off. Recharge the NiMH batteries as described on page
C–24.
3–26
NOTE
