PROJECT FILES

The Model 3451 stores measurement results in files called projects,
which are named by the operator. The Project function allows the
operator to create a new project, view project data, erase projects,
enable a project (make an existing project active so that additional
data may be added to it), or disable the active project.
The gauge will not take a reading unless a project has
been created and is active.
To access the Project function, press 〈Project Access〉 on the
main menu (see Figure 3–11). The PDA displays the Project
Menu shown in Figure 3–12.
When checked, the Disable Storage to Gauge check box
prevents the PDA from storage measurement data to the gauge for
storage following a reading. The Disable Project Notes check
box disables the Would you like to add project notes? prompt
that otherwise is displayed following a measurement.
The following sections describe the other functions available from
the Project Menu.
The Project function cannot be used to enter target
values, offsets, or special calibrations. For information
on entering target values, see page 5–14. For
information on using offsets and special calibrations,
refer to Chapter 6.

NEW PROJECT

To create a new project, press the 〈New〉 button on the Project
Menu shown in Figure 3–12. The PDA displays the first page of the
setup Wizard for a new project, as shown in Figure 3–13.
Model 3451
NOTE
NOTE
3–19
