- Page 1 Instruction Manual MODEL 3216 ROOF MOISTURE GAUGE Troxler Electronic Laboratories, Inc. 3008 Cornwallis Rd. P.O. Box 12057 Research Triangle Park, NC 27709 Phone: 1.877.TROXLER Outside the USA: +1.919.549.8661 Fax: +1.919.549.0761 www.troxlerlabs.com...
- Page 2 Troxler Gauges are protected by U.S. and foreign patents Copyright © 1981 - 2006 Troxler Electronic Laboratories, Inc. All Rights Reserved No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording,...
- Page 3 NOTES SAFETY ALERT SYMBOL The Safety Alert Symbol shall appear within this manual. Wherever it appears in this manual or on safety signs affixed to the machine, this is to make all aware of the potential for personal injury and to be cautious when these images are present. Always observe all WARNING, CAUTION, and NOTE recommendations listed within this manual before operating the machine.
- Page 4 TROXLER SERVICE CENTERS Troxler Corporate Headquarters 3008 Cornwallis Road P.O. Box 12057 Research Triangle Park, NC 27709 Phone: 1.877.TROXLER (1.877.876.9537) Outside the U.S.A.: +1.919.549.8661 Fax: +1.919.549.0761 Web: www.troxlerlabs.com Technical Support Phone: 1.877.TROXLER (1.877.876.9537) E-mail: TroxTechSupport@troxlerlabs.com Midwestern Branch Office Florida Service Center...
- Page 5 TABLE OF CONTENTS INTRODUCTION AND SPECIFICATIONS I-A. Introduction ....1-1 I-B. Definition of Terms ... 1-2 I-C.
- Page 6 Table of Contents (cont'd) X-B-4. 3216 Radiation Profile ..10-6 X-B-5. Source Encapsulation ... 10-7 X-B-6. Emergency Procedures ... 10-7 XI.
- Page 7 Block Diagram of Gauge Electronics Statistical Test Data Neutron Interaction Data Effect of Neutron Source-Detector Distance Effect of Moisture on Depth of Measurement 3216 Calibration Data Graphic Interpretation of Moisture Calibration 10-1 Diagram of an Atom 10-1 10-2 Variation of Radioactive Emission...
- Page 8 This page intentionally blank...
- Page 11 Largest Number Displayable 9999 Count Registers Power Consumption 0.08 W Power Consumption after 0.001 W Automatic Battery Cutoff Battery packs are fully protected against overcharge and overdischarge. Low Battery alarm is indicated on the display several hours prior to automatic cutoff. TROXLER...
- Page 16 If a limited number of core samples are to be cut, then they should be made at sites (determined from the count data) that indicate a transition from dry to wet. TROXLER...
- Page 40 VI-E. TROXLER SERVICE CENTERS Troxler Corporate Headquarters 3008 Cornwallis Road P.O. Box 12057 Research Triangle Park, NC 27709 Phone: 1.877.TROXLER (1.877.876.9537) Outside the U.S.A.: +1.919.549.8661 Fax: +1.919.549.0761 Web: www.troxlerlabs.com Technical Support Phone: 1.877.TROXLER (1.877.876.9537) E-mail: TroxTechSupport@troxlerlabs.com Midwestern Branch Office Florida Service Center...
- Page 41 12 V DC Charger Cable 103367 Instruction Manual 104508 AC Battery Charger, 13.5 V, 140 mA (Dom. Sales) 104509 AC Battery Charger, 13.5 V, 140 mA (Int. Sales) 104621 3216 Case/Foam Ass'y 109661 Troxler Survey Meter "marking stick" useful spot marking grid intersection points on the roof.
- Page 49 During the development of moisture measurement gauges, Troxler Electronic Laboratories, Inc. developed a set of standards made from laminated sheets of plastic and a non-absorber of thermal neutrons. This process has been patented (.) During the process of manufacture the ratio...
- Page 50 An example of a typical Model 3216 calibration report is shown in Figure 9-1. A summary of the contents of a Model 3216 calibration report is presented hereunder. The report consists of six separate parts, contained on two pages: 1.
- Page 51 Figure 9-2, a plot of a calibration curve for a Model 3216 gauge, includes a graphic illustration of precision. 6. The second page of the calibration report begins with the header, followed by six paragraphs of summary information.
- Page 52 IX.B. MOISTURE PERFORMANCE PARAMETERS (cont’d) Troxler Model 3216 Calibration Report - Page 1 of 2 Model: 3216A Serial: 00512 Calib. date: Mar 21, 2005 Source: AM-241/Be Serial: 78-976 Print date: Dec 07, 2005 Neutron Surface Moisture Gauge ****** The performance parameters, calibration constants, and moisture values for this instrument are listed both in SI units (kilograms per cubic meter) and in US Customary Units (pounds per cubic foot).
- Page 53 IX.B. MOISTURE PERFORMANCE PARAMETERS (cont’d) Troxler Model 3216 Calibration Report - Page 2 of 2 Model: 3216A Serial: 00512 Calib. date: Mar 21, 2005 Source: AM-241/Be Serial: 78-976 Print date: Dec 07, 2005 Neutron Surface Moisture Gauge ****** The calibration parameters for this instrument are based upon the measured material having a uniform moisture content equally distributed throughout the measured depths.
- Page 54 IX.B. MOISTURE PERFORMANCE PARAMETERS (cont’d) Graphic Interpretation of Moisture Calibration Figure 9-2 TROXLER...
- Page 55 TROXLER 10-1...
- Page 56 (Ci). The Curie is defined as 3.7 x 10 disintegrations of nuclei per second. In the "special form," encapsulated sealed source used in the 3216, the unit of measure is the millicurie (1/1,000 of a curie). The SI unit of radiation is the Becquerel (Bq).
- Page 57 RADIATION SAFETY This section provides a brief discussion of general radiation safety. The exposure profile for the Model 3216 gauge is also included, along with a discussion of the source encapsulation. X-B-1. TYPES OF RADIATION The radioactive source in the Model 3216 produces three...
- Page 58 (i.e. water, polyethylene, etc.). Neutrons have a neutral charge and are very penetrating. X-B-2. LIMITING EXPOSURE Under normal conditions a full time operator of the 3216 will receive less than 150 millirem per year. Taking advantage available means limit radiation exposure is always recommended.
- Page 59 The current limit in the United States and many other countries is 5,000 millirem per year. Under average conditions a full time employee working with the 3216 will receive less than 150 millirem per year. Anyone working with or near radioactive materials is...
- Page 60 0.20 BACK SIDES 0.15 1.55 BOTTOM 1.00 HANDLE 0.15 0.15 RADIATION PROFILE FOR 3216 GAUGE IN PLASTIC CASE SURFACE 10 cm 30 cm LOCATION Gamma Neutron Total Gamma Neutron Total Gamma Neutron Total Gamma Neutron Total LEFT BACK RIGHT FRONT...
- Page 61 It is, however, required that personnel dosimetry be used when using the 3216. X-B-6. EMERGENCY PROCEDURES If the nuclear gauge is lost or stolen, then immediately notify the Radiation Safety Officer (RSO).
- Page 62 The RSO may also be required to notify the USDOT of accidents during transport. Before shipping a damaged gauge to Troxler, obtain a RGA (returned goods authorization) number from the Troxler RSO. 10-8...
- Page 63 The major requirements for transporting a nuclear gauge in the United States are listed below. For more detailed information about these requirements, please refer to the Troxler Transportation Guide. A copy of the current IAEA Certificate of Competent Authority for each source in the gauge (Special Form Certificate) must be kept on file.
- Page 64 Canada. For training and accident notification requirements, consult Transportation Dangerous Goods Regulations. For further information on transporting a nuclear device, contact the transportation section of The Canadian Nuclear Safety Commission (CNSC). 11-2 TROXLER...
- Page 65 APPENDIX...
