GAUGE PARTS AND ACCESSORIES

Figure 1–1 shows the gauge and its accessories.
1. The Gauge is the portable instrument containing electronic
modules, a cordless serial adapter with Bluetooth wireless
technology, a rechargeable battery pack, detectors, and the
radioactive sources.
2. The Intermec
provides the operator interface with the gauge. Included with
the PDA are a stylus, a rechargeable battery pack, a serial cable,
a dc adapter used to charge the PDA from an automobile
cigarette lighter, a universal ac adapter and ac power cord used
to charge the PDA from an ac outlet, a Quick Start Guide, and a
Pocket PC Companion CD containing Microsoft ActiveSync
software.
3. The Transport Case for the Model 3451 is a Type A package.
Always use a Type A package to ship the Model 3451.
4. The Reference Standard Block provides a measurement
standard for standard counts. It is also used during stability and
drift tests.
5. The Scraper Plate/Drill Rod Guide is used to prepare the test
site and to guide the drill rod when preparing the source rod
hole for direct transmission measurements.
6. The Drill Rod is used to drill holes for direct transmission
measurements. Do not use the gauge source rod to drill holes.
7. The Extraction Tool provides leverage to remove the drill rod
from soil materials.
8. The Model 3451 Manual of Operation and Instruction details
how to use the gauge. Both the manual and the Transportation
Guide discuss radiation safety and gauge shipping concerns.
9. The AC Charger and DC Adapter are used to charge the gauge
batteries. The ac charger accepts 110 (220 and European
optional) V ac, 50/60 Hz and supplies 12 V dc. The dc adapter
allows recharging from an automobile cigarette lighter.
10. The Data Manager PDA to PC Model 3451 for Windows XP
software includes tools for retrieving and managing project data
from the PDA or gauge. This software is provided on CD-ROM
(not shown).
1–8

700 Series Color Mobile Computer, or PDA,
