Type A Package Testing Results for Model 3451
Water Spray Test:
Results:
Vibration Test:
Results:
Free Drop Test:
Results:
Penetration:
Results:
Compression:
Results:
Weight of package as tested: 96 pounds
Date test completed: July 1996
Figure D–1. Type A Package Testing Results
Appendix D–4
Subject the package to a water spray simulating rainfall
of approximately 2 inches per hour for 1 continuous
hour.
Engineering evaluation – Water exposure of the
magnitude required by the regulations would not affect
the shielding or containment integrity of the package.
The package was vibrated with a displacement of 0.1"
at approximately 12 Hz for a period of 24 continuous
hours.
No physical damage to the package was observed.
The package was dropped from a height of 4 feet onto a
non-yielding surface from a position to cause
maximum damage to the package.
The case was scratched due to the abrasiveness of the
concrete, but no other physical damage to the package
was observed.
The package was placed on a non-yielding surface. A
1-1/4-inch diameter, 13-pound steel cylinder with a
hemispherical end was dropped in the vertical position
from a height of 40 inches onto the package to a point
to cause maximum damage to the package.
No physical damage to the package was observed.
Package was placed on a non-yielding surface and
subjected to a compressive load of at least 13
kilopascals multiplied by the vertically projected area
of the package, in square feet, for 24 continuous hours.
No physical damage to the package was observed.
