Troxler Enhanced RoadReader Plus 3451 Manual Of Operation And Instruction page 11

Figure Title
1–1 Model 3451 Parts and Accessories ............................ 1–9
2–1 Effect of Moisture on Depth of Measurement ........... 2–4
3–1 Model 3451 Illustration ............................................. 3–3
3–2 Back Panel Details .....................................................3–4
3–3 Source Rod Positions ................................................. 3–5
3–4 Troxler Menu ........................................................... 3–10
3–5 Notes Screen ............................................................ 3–10
3–6 Calculator ................................................................. 3–11
3–7 Intermec Launcher Display ...................................... 3–12
3–8 Windows Desktop .................................................... 3–12
3–9 Return to Troxler Menu ........................................... 3–13
3–10 Battery Status Display ............................................. 3–17
3–11 RoadReader Plus Software Main Menu ................... 3–18
3–12 Project Menu ............................................................ 3–20
3–13 New Project Setup Wizard, Page 1 .......................... 3–20
3–14 Project File Selector ................................................. 3–22
3–15 Project Data Display ................................................ 3–22
3–16 Project Erase Prompt ............................................... 3–23
3–17 Gauge Tools Menu. .................................................. 3–24
3–18 Gauge Status Menu .................................................. 3–24
3–19 View Status Display................................................. 3–25
3–20 View Constants Display ........................................... 3–25
3–21 Source Decay Menu ................................................. 3–27
3–22 GPS Location Display ............................................. 3–28
4–1 Standard Menu ........................................................... 4–2
4–2 Standard Count Position ............................................ 4–3
4–3 Standard Count Results ..............................................4–5
4–4 View Standard Screen ................................................ 4–6
4–5 Drill Rod Assembly ................................................... 4–8
4–6 Marking the Test Area ............................................... 4–8
4–7 Entering Project Notes ............................................. 4–12
4–8 Count Results, Soil Mode ........................................ 4–13
4–9 Count Results, Asphalt Mode .................................. 4–16
4–10 Gauge Positioned Around a Core Site ..................... 4–18
Model 3451
LIST OF FIGURES
Page
x
