3451 RADIATION PROFILE

Table A–1 shows the radiation profile for the Model 3451 gauge.
The table lists the radiation dose equivalent rates (in mrem/hour) for
each side of the gauge and transport case shown in Figure A–4.
TOP
LEFT SIDE
BACK
FRONT
BOTTOM
RIGHT SIDE
GAUGE
LEFT SIDE
TOP
BACK
BOTTOM
FRONT
RIGHT SIDE
TRANSPORT CASE
Figure A–4. Model 3451 Gauge and Transport Case
Model 3451 Appendix A–19
