Manual of Operation and Instruction
Model 3451
Enhanced
RoadReader™ Plus
Surface Moisture-Density Gauge
NOTE
The Model 3451 Enhanced RoadReader Plus is equipped with a
global positioning system (GPS) receiver. If the gauge is moved
a long distance between uses, the GPS system must be allowed
to initialize. In some instances, initialization may take as long as
30 to 45 minutes from the time the gauge is powered on with the
GPS enabled. Note also that the gauge must be positioned such
that the GPS receiver can receive signals from the GPS
satellites (see page 1–5 for more information). If the GPS does
not initialize within 45 minutes, contact your Troxler
representative.
Troxler Electronic Laboratories, Inc.
3008 Cornwallis Rd. • P.O. Box 12057
Research Triangle Park, NC 27709 U.S.A.
Phone: 1.877.TROXLER
Outside the USA: +1.919.549.8661
Fax: +1.919.549.0761
www.troxlerlabs.com
