14.10 Command: Until

Until condition. You must have Until conditions for stopping a direction movement, tap the Add
Until button to define the stop criteria.

Stopping a Direction Movement

You can add Direction Vector settings, for Tool Speed and Tool Acceleration, to define the vector
direction for linear motion, allowing for advanced uses as:
• defining linear motion relative to multiple feature axes
• computing the direction as a mathematical expression
The Direction Vectors defines a custom code expression that is resolved to a unit vector. For ex-
ample, for a vector of [2,1,0] the robot moves two units in the x direction for every unit in the y
direction, relative to the specified speed.
14.10 Command: Until
The program node Until defines a stop criterion for a motion. The robot moves along a path and
stops when contact is detected.
Version 3.10 II-85 CB3
