Set type of PLC outputs (Source, Sink, Source/Sink)
-> refer chapter 5.4
-> refer chapter 5.4
Set PLC output to logic 1 (level according SOT, SOA)
Equivalent to SO, but set all outputs binary coded
Clear output (level according SOT, SOA)
Preload output number for output function assignment with
Assign type of output function to the with NOF preloaded
output number (0 = no function, 1 = REF, 2 = INMO, 3 = EDPG,
4 = TGR, 5 = ERR, 6 = BRK, 7 = INPO, 8 = IFML, 9 = IFSE,
10 = INSE, 11 = INFO, 12 = WARN, 13 = INFM, 14 = STO1,
15 = STO2, 16 = SS11, 17 = SS12, 18 = SS21, 19 = SS22,
Trigger upward counting, absolute, at output #x defined in
Trigger downward counting, absolute, at output #x defined in
0=all Input HIGH active, 1= all Input LOW active,
2= individual input activity selection according to ILAS (value 0
and 1 puts ILAS to 0x000 respectively 0xFFF)
individual input activity selection, 0=Input HIGH active,
1. Hex for value binary inputs 9-12 only 0 or F, 2. And 3. Hex
value for input 1-8 (values 0x000 and 0xFFF put ILA to 0 resp. 1.
Status single input, 0 = Low 1 = High
Preload input number for input function assignment with
Assign type of input function to the with NIF preloaded input
number (0 = no function, 1 = REF, 2 = IX, 3 = PG, 4 = SO, 5 = CO,
6 = JP, 7 = JN, 8 = CPOS, 9 = IP, 10 = SI, 11 = SIC, 12 = LS-,
13 = LS+,14 = EE, 15 = EE1, 16 = PWC, 17 = PRF, 18 = RSTO,
19 = OVRD, 20 = PGEX, 21 = DIF, 22 = PQ)
Parameter A of input function of with NIF preloaded input
number (value depending on input function, according to value
described in chapter 10.13.1 Selection of Input Functions)
Parameter B of input function of with NIF preloaded input
number (value depending on input function, according to value
described in chapter 10.13.1 Selection of Input Functions)
Shows present position captured with input
Shows the position captured with input 12
DESCRIPTION
Output Configuration
High / Low Activity of PLC outputs
Output Configuration
Bit 0 = Output 1, Bit 7 = Output 8
Status all Outputs,
0= logic 0, 1=logic 1
Status all Outputs in HEX format
command TYOF
20 = SLS1, 21 = SLS2)
Output-Function, pulse during 5ms
Output-Function, pulse during 5ms
1=Input LOW active
All other values are to 2 by ILA
Status all inputs, 0 = Low, 1 = High
/ ? incl. indication of input number
Status all Inputs in HEX format
command TYIF
10.6.13 Input / Output
Short CMD
Set Output Type SOT
Set Output Activity SOA
Set Output SO
Set Output Hex SOX
Clear Output CO
Tell Output TO
Tell Output HEX TOX
Number Output Function NOF
Type Output Function TYOF
Trigger upward TGU
Trigger downward TGD
Input LOW active ILA
Input Low Active Single ILAS
Tell Input TI
Tell Input TI
Tell Input HEX TIX
Number Input Function NIF
Type Input Function TYIF
Parameter A PAIF
Parameter B PBIF
Tell Capture Position TCP
Tell Capture Pos. Buffer TCPB
PARAMETER
0-65535
0-255
1-8
00-FF
1-8
1-8
0-21
± 2'000'000'000 Increment
± 2'000'000'000 Increment
0-2 / ?
0xx / Fxx / ?
1-12 / ?
1-12
1-8
0-22
xx
yy
1-8
1-8
