LINAX® Linear Motors
3 phase synchronous linear motor with encoder
RS422 A/A*, B/B* und Z/Z* and distance-coded
Linear motor identification and temperature
ELAX® Electric Slides with Linear
ELAX® is the evolutionary step of the widespread
pneumatic slides. The great accomplishment is the
patented compact integration of the linear motor in
the slider case, resulting in a force/volume ratio
which has hitherto never been achieved.
Linear motor identification and temperature
ROTAX® Rotary motor axes
Specifically designed for fast and precise assembly
and handling tasks. It can be equipped with standard
gripping tools. The hollow shaft feedthrough for
vacuum or compressed air enables a 360° rotation.
The XENAX® servo controller identifies the ROTAX®
rotary axis and configures the controller parameters
reference marks.
Special feature:
monitoring over I2C bus.
Motor
Special feature:
monitoring over I2C bus.
automatically.

2 Controllable Motor Types

2.1 Linear Motor Axes and Electric Slides

2.2 Servo Motors in our Product Line

Rxhq = high torque Rxvp = vacuum pressure
