Securing the System

007-4263-001
The Silicon Graphics 230 Visual Workstation's side panel can be locked into place on the
system using a locking loop and a padlock, thus preventing access to the internal
components of the system. The locking loop is stored in a slot on the chassis and needs
to be moved to another slot to be used. Follow these steps to install the locking loop:
1. Remove the side panel if not already done. For removal of the side panel, refer to
"Pre-installation Instructions" on page 16.
2. Locate the locking loop. See Figure 2-28 for the location of the locking loop.
1
2
2
1
Figure 2-28 Location of Locking Loop
Locking loop
Locking loop slot
Securing the System
51
